      Constant Voltage North American Series (www.tafu-power.com)

      Features
      -
      Constant Voltage Triac Dimmable Driver
      - Support Forward phase/Reverse phase/ELV/MLV/Triac dimming.
      - Full range input voltage 100-277VAC.
      - Soft 0.1~100% dimming and flicker-free at any brightness.
      - Suitable for LED indoor lighting, office lighting, commercial lighting, etc.
      Parameters
      -

      Please browse our dedicated LED driver website on www.tafu-power.com for detailed information!



      Picture Product Series Part No.  Power Input Voltage Output
      Voltage       		 Dimension
      (L*W*H)      		 Certificate

      Constant Voltage
      5 in 1 Dimming Series

      (Traic & 0/1-10V &

       10V PWM & Rx)

      Dimming)

      		 TMC-12/24V
      030W-VWA      		 30W 100-277VAC DC
      12V/24V      		 L172*W87.5*H41mm
      (L6.8*W3.4*H1.6in.)       		 UL CUL Class P
      TYPE HL SELV Class 2
      TMC-12/24V
      030W-VWA      		 60W 100-277VAC DC
      12V/24V      		 L195*W96.5*H41mm
      (L7.7*W3.8*H1.6in.)      		 UL CUL Class P
      TYPE HL SELV Class 2
      TMC-12/24V
      096W-VWA      		 96W 100-277VAC DC
      12V/24V      		 L220.5*W96.5*H41mm
      (L8.7*W3.8*H1.6in.)      		 UL CUL Class P
      TYPE HL SELV Class 2
      TMC-12/24V
      150W-VWA      		 150W 100-277VAC DC
      12V/24V      		 L252.5*W109*H41mm
      (L9.9*W4.3*H1.6in.)      		 UL CUL Class P
      TYPE HL SELV
      TMC-24/48V
      192W-VWB

      192W

      (96W*2)

      		 100-277VAC DC
      24V/48V      		 L252.5*W109*H41mm
      (L9.9*W4.3*H1.6in.)      		 UL CUL Class P
      TYPE HL SELV Class 2
      TMC-24/48V
      288W-VWB

      288W

      (96W*3)

      		 100-277VAC DC
      24V/48V      		 L297.5*W109*H41mm
      (L11.7*W4.3*H1.6in.)      		 UL CUL Class P
      TYPE HL SELV Class 2

      Constant Voltage

      Triac

      Dimming Series

      		 TPL-12/24V
      030W-TDA      		 30W 100-277VAC DC
      12V/24V      		 L262*W30*H20mm
      (L10.3*W1.2*H0.8in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TPL-12/24V
      060W-TDA      		  60W

      100-277VAC

      		 DC
      12V/24V      		 L302*W30*H20mm
      (L11.9*W1.2*H0.8in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TPL-12/24V
      096W-TDA      		 96W

      100-277VAC

      		 DC
      12V/24V      		 L332*W30*H22mm
      (L13.1*W1.2*H0.9in.)      		 UL CUL Class P
      TYPE HL SELV
      TFL-12/24V
      030W-TDA      		 30W

      100-277VAC

      		 DC
      12V/24V      		 L156*W55*H20mm
      (L6.1*W2.2*H0.8in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TFL-12/24V
      060W-TDA      		 60W

      100-277VAC

      		 DC
      12V/24V      		 L180*W60*H25mm
      (L7.1*W2.4*H1in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TFL-12/24V
      096W-TDA      		 96W

      100-277VAC

      		 DC
      12V/24V      		 L205*W60*H25mm
      (L8.1*W2.4*H1in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TML-12/24V
      030W-TWA      		 30W

      100-277VAC

      		 DC
      12V/24V      		 L262*W32*H20mm
      (L10.3*W1.3*H0.8in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TML-12/24V
      060W-TWA      		 60W

      100-277VAC

      		 DC
      12V/24V      		 L302*W32*H20mm
      (L11.9*W1.3*H0.8in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TML-12/24V
      096W-TWA      		 96W

      100-277VAC

      		 DC
      12V/24V      		 L332*W32*H24mm
      (L13.1*W1.3*H0.9in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TMS-12/24/
      48V150W-TWA      		 150W

      100-277VAC

      		 DC12V/
      24V/48V      		 L245*W78*H46mm
      (L9.7*W3.1*H1.8in.)      		 UL CUL Class P
      TYPE HL SELV FCC
      TMS-12/24/
      48V300W-TWA      		 300W 100-277VAC DC12V/
      24V/48V      		 L264*W78*H46mm
      (L10.4*W3.1*H1.8in.)      		 UL CUL Class P
      TYPE HL SELV FCC





      Picture Product Series Part No.  Power Input Voltage Output
      Voltage       		 Dimension
      (L*W*H)      		 Certificate

      Constant Voltage

      4 in 1 Dimming Series

      (0/1-10V &

      10V PWM & Rx)

      Dimming)

      		 TPL-12/24V
      030W-MDA      		 30W 100-277VAC DC
      12V/24V      		 L262*W30*H20mm
      (L10.3*W1.2*H0.8in.)      		 UL CUL Class P TYPE
      HL SELV FCC Class2
      TPL-12/24V
      060W-MDA      		 60W 100-277VAC DC
      12V/24V      		 L302*W30*H20mm
      (L11.9*W1.2*H0.8in.)      		 UL CUL Class P TYPE
      HL SELV FCC Class2
      TPL-12/24V
      096W-MDA      		 96W 100-277VAC DC
      12V/24V      		 L332*W30*H22mm
      (L13.1*W1.2*H0.9in.)      		 UL CUL Class P
      TYPE HL SELV FCC
      TFL-12/24V
      030W-MDA      		 30W 100-277VAC DC
      12V/24V      		 L156*W55*H20mm
      (L6.1*W2.2*H0.8in.)      		 UL CUL Class P TYPE
      HL SELV FCC Class2
      TFL-12/24V
      060W-MDA      		 60W 100-277VAC DC
      12V/24V      		 L180*W60*H25mm
      (L7.1*W2.4*H1in.)      		 UL CUL Class P TYPE
      HL SELV FCC Class2
      TFL-12/24V
      096W-MDA      		 96W 100-277VAC DC
      12V/24V      		 L205*W60*H25mm
      (L8.1*W2.4*H1in.)      		 UL CUL Class P TYPE
      HL SELV FCC Class2
      TML-12/24V
      030W-MWA      		 30W 100-277VAC DC
      12V/24V      		 L262*W32*H20mm
      (L10.3*W1.3*H0.8in.)

      UL CUL Class P
      TYPE HL SELV Class2
      TML-12/24V
      060W-MWA      		 60W 100-277VAC DC
      12V/24V      		 L302*W32*H20mm
      (L11.9*W1.3*H0.8in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TML-12/24V
      096W-MWA      		 96W 100-277VAC DC
      12V/24V      		 L332*W32*H24mm
      (L13.1*W1.3*H0.9in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TMS-12/24/
      48V150W-MWA      		 150W 100-277VAC DC12V/
      24V/48V      		 L245*W78*H46mm
      (L9.7*W3.1*H1.8in.)      		 UL CUL Class P
      TYPE HL SELV FCC
      TMS-12/24/
      48V300W-MWA      		 300W  100-277VAC DC12V/
      24V/48V      		 L264*W78*H46mm
      (L10.4*W3.1*H1.8in.)      		 UL CUL Class P
      TYPE HL SELV FCC

      Constant Voltage

      ON/OFF Series

      		 TPL-12/24V
      030W-NDA      		 30W 100-277VAC DC
      12V/24V      		 L262*W30*H20mm
      (L10.3*W1.2*H0.8in.)      		 UL CUL Class P TYPE
      HL SELV FCC Class2
      TPL-12/24V
      060W-NDA      		 60W 100-277VAC DC
      12V/24V      		 L302*W30*H20mm
      (L11.9*W1.2*H0.8in.)      		 UL CUL Class P TYPE
      HL SELV FCC Class2
      TPL-12/24V
      096W-NDA      		 96W 100-277VAC DC
      12V/24V      		 L332*W30*H22mm
      (L13.1*W1.2*H0.9in.)      		 UL CUL Class P
      TYPE HL SELV FCC
      TFL-12/24V
      030W-NDA      		 30W 100-277VAC DC
      12V/24V      		 L156*W55*H20mm
      (L6.1*W2.2*H0.8in.)      		 UL CUL Class P TYPE
      HL SELV FCC Class2
      TFL-12/24V
      060W-NDA      		 60W 100-277VAC DC
      12V/24V      		 L180*W60*H25mm
      (L7.1*W2.4*H1in.)      		 UL CUL Class P TYPE
      HL SELV FCC Class2
      TFL-12/24V
      096W-NDA      		 96W 100-277VAC DC
      12V/24V      		 L205*W60*H25mm
      (L8.1*W2.4*H1in.)      		 UL CUL Class P TYPE
      HL SELV FCC Class2
      TML-12/24V
      030W-NWA      		 30W 100-277VAC DC
      12V/24V      		 L262*W32*H20mm
      (L10.3*W1.3*H0.8in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TML-12/24V
      060W-NWA      		 60W 100-277VAC DC
      12V/24V      		 L302*W32*H20mm
      (L11.9*W1.3*H0.8in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TML-12/24V
      096W-NWA      		 96W 100-277VAC DC
      12V/24V      		 L332*W32*H24mm
      (L13.1*W1.3*H0.9in.)      		 UL CUL Class P
      TYPE HL SELV Class2
      TMS-12/24/
      48V150W-NWA      		 150W 100-277VAC DC12V/
      24V/48V      		 L245*W78*H46mm
      (L9.7*W3.1*H1.8in.)      		 UL CUL Class P
      TYPE HL SELV FCC
      TMS-12/24/
      48V300W-NWA      		 300W 100-277VAC DC12V/
      24V/48V      		 L264*W78*H46mm
      (L10.4*W3.1*H1.8in.)      		 UL CUL Class P
      TYPE HL SELV FCC
      Download
      -

      • Datasheet - Constant Voltage North American Series

      Details
      -

      Please browse our dedicated LED driver website on www.tafu-power.com for detailed information!
